Electroplating Barrel

Barrel plating is considered as the best low cost economical bulk small articles plating process such as screws , rivets, nuts, etc. This completely eliminates racking and rack maintenance cost, ultimately reducing the cost of production. Fully immersed barrel can be used in any plating process except chrome plating. This unit is consisted by M. steel tank duly lined by as per customer specification. Fitted with gearbox & motor for suitable rotation consisting of perforated acrylic or PP made barrel complete with mechanical lifting system along with hopper, busbar connection and weight.

Transporter Wagon

We manufacture transporter wagon for semi automatic plating process such as screws, rivets, nuts, etc. Plating barrel can move east & west, up & down lifting in the row of plating process tank by this unit. This unit is consisting by M.S channel & M.S sheeted body duly fitted with 2HP 440volt AC motor & reduction gearbox size depends on the clients specifications.

Filter Unit

We offer a wide range of magnetic drive filter units, which are suitable for delivering general plating solutions. These units consist of motor driven polypropylene pump with a mechanical seal or a magnetic drive pump without seal. Further, our range also comprises of the following features:

• Filter chamber made of acrylic
• M.S lined with PPGL
• Complete FRP body

Our range is mounted on a trolley for easy movement and are suitable for acid and alkaline solutions having temperature up to 70 degree centigrade.
